Caster / Series 2/4

Heavy duty caster, pressed steel with yellow zinc plating fork, 76F:PU wheel with cast Alu center, double ball bearing

Heavy duty steel housing with yellow zinc plating.

Heavy duty polyurethanewheel tread, aluminium center

Double ball bearings

•

•

•

Item Code	Wheel Diameter (mm)	Wheel Thick (mm)	Weight (kg)	Total Height (mm)	Eccentric Throw (mm)	Plate Hole (mm)	Plate Dimension (mm)	Plate Hole Spacing (mm)	Barrier Width (mm)
P160-76F125x50	125	50	400	166	55	12	135x110x6	105×80	4.5
P160-76F150x50	150	50	550	194.5	55	12	135x110x6	105×80	4.5
P160-76F160x50	160	50	600	199.5	55	12	135x110x6	105×80	4.5
P160-76F200x50	200	50	800	241	55	12	135x110x6	105×80	4.5
P160-76F250x50	250	50	800	291	55	12	135x110x6	105×80	4.5
D160-76F125x50	125	50	400	166	/	12	135x110x6	105×80	3.5
D160-76F150x50	150	50	550	194.5	/	12	135x110x6	105×80	3.5
D160-76F160x50	160	50	600	199.5	/	12	135x110x6	105×80	3.5
D160-76F200x50	200	50	800	241	/	12	135x110x6	105×80	3.5
D160-76F250x50	250	50	800	291	/	12	135x110x6	105×80	3.5
P160-76F125x50S	125	50	400	166	55	12	135x110x6	105×80	4.5
P160-76F150x50S	150	50	550	194.5	55	12	135x110x6	105×80	4.5
P160-76F160x50S	160	50	600	199.5	55	12	135x110x6	105×80	4.5
P160-76F200x50S	200	50	800	241	55	12	135x110x6	105×80	4.5
P160-76F250x50S	250	50	800	291	55	12	135x110x6	105×80	4.5
